AX-3227

AX-3227

3.0T Mid-Rise Scissor LIft



0.00
0.00


3.0T Mid-Rise Scissor LIft



PRODUCT SPECIFICATIONS
Item
Data
Lifting capacity:
3000kg
Lifting height:
1000mm
Min.height:
110mm
  Length of The Platform   1400mm
  Platform Width   530mm
   Air Pressure   0.6-0.8Mpa
Lifting time:
50-60s
Oil Pressure Rating:
24MPa
Motor power:
2.2kw- 220V/380V
Weight:
580Kg

Product Description

1.The lifting platform extension, according to the different models of the vehicle support the ramp and extension, flexible use,cover small space.

2.Pneumatic release, safe and reliable.

3.The initial height is low (110mm),have sliding ramp and extension.

4.Adopt axis drived, synchronization performance good, lifting capacity well.

5.Hydraulic system adopted imported electromaonetic valve and seal components,ensure the stability and working life of the machine.

6.When the power supply is off, lift and vehicle can be down by manual.

7.Rising and falling have safety alarm device.

8.Oil cylinder with upper return oil, prevent oil cylinder rust.
